Chip Inductors for RF Applications (wire wound - open) >> 0402AS Series

0402AS

Technical Data & Specifications :

Complete Data Sheet :

Print :


Part No Inductance
L (nH)
fL
(MHz)
Tol
± (%)
Q
min
fQ
(MHz)
SRF
(MHz)
DCR
max
(Ω)
Rated DC
Current
max (mA)
Get Sample
0402AS-0N9K-YY 0.9 250 10 11 250 6000 min 0.04 1360
0402AS-1N0K-YY 1.0 250 10 11 250 6000 min 0.07 700
0402AS-1N2K-YY 1.2 250 10 11 250 6000 min 0.11 700
0402AS-1N8K-YY 1.8 250 10 16 250 6000 min 0.07 1040
0402AS-1N9K-YY 1.9 250 10 16 250 6000 min 0.07 1040
0402AS-2N0K-YY 2.0 250 10 16 250 6000 min 0.07 1040
0402AS-2N2K-YY 2.2 250 10 14 250 6000 min 0.11 640
0402AS-2N4K-YY 2.4 250 10 16 250 6000 min 0.12 640
0402AS-2N5K-YY 2.5 250 10 16 250 6000 min 0.12 640
0402AS-2N7K-YY 2.7 250 10 16 250 6000 min 0.12 640
0402AS-2N9K-YY 2.9 250 10 16 250 6000 min 0.10 700
0402AS-3N3K-YY 3.3 250 10 20 250 6000 min 0.10 700
0402AS-3N6K-YY 3.6 250 10 19 250 6000 min 0.10 700
0402AS-3N9K-YY 3.9 250 10 19 250 4800 min 0.10 700
0402AS-4N3K-YY 4.3 250 10 18 250 6000 min 0.091 700
0402AS-4N7K-YY 4.7 250 10 15 250 4775 min 0.130 640
0402AS-5N1J-YY 5.1 250 5 23 250 4800 min 0.083 800
0402AS-5N6J-YY 5.6 250 5 22 250 4800 min 0.110 760
0402AS-6N2J-YY 6.2 250 5 20 250 4800 min 0.110 760
0402AS-6N8J-YY 6.8 250 5 21 250 4800 min 0.100 680
0402AS-7N5J-YY 7.5 250 5 24 250 4800 min 0.100 680
0402AS-8N2J-YY 8.2 250 5 24 250 4400 min 0.100 680
0402AS-8N7J-YY 8.7 250 5 22 250 4160 min 0.160 681
0402AS-9N0J-YY 9.0 250 5 22 250 4160 min 0.160 681
0402AS-9N1J-YY 9.1 250 5 22 250 4000 min 0.200 480
Material
Ceramic
Engineer's Kits
EK-0402AS-X
Remarks

Packing Standard
Taped / Reel
1000 [-08]
5000 [-01]
