Chip Inductors for RF Applications (Wire wound - open)

0402ASM New!

Technical Data & Specifications :

Complete Data Sheet :

Print :


Part No Inductance
L (nH)
fL
(MHz)
Tol
± (%)
Q
min
fQ
(MHz)
SRF
(MHz)
DCR
max
(Ω)
Rated DC
Current
max (mA)
Get Sample
0402ASM-1N0K-YY 1.0 250 10 69 900 12700 0.045 1430
0402ASM-1N8K-YY 1.8 250 10 54 900 12000 0.055 1220
0402ASM-1N9K-YY 1.9 250 10 63 900 11300 0.055 1220
0402ASM-2N0K-YY 2.0 250 10 62 900 11300 0.060 1170
0402ASM-2N2K-YY 2.2 250 10 59 900 10800 0.065 1220
0402ASM-3N3K-YY 3.3 250 10 59 900 7000 0.065 690
0402ASM-3N6K-YY 3.6 250 10 55 900 6800 0.065 820
0402ASM-3N9K-YY 3.9 250 10 50 900 6000 0.065 780
0402ASM-4N3K-YY 4.3 250 10 50 900 6000 0.065 700
0402ASM-010J-YY 10 250 5 50 900 3900 0.160 550
0402ASM-012J-YY 12 250 5 50 900 3600 0.200 550
0402ASM-015J-YY 15 250 5 50 900 3660 0.200 530
0402ASM-018J-YY 18 250 5 54 900 3100 0.200 530
0402ASM-022J-YY 22 250 5 53 900 2800 0.300 420
0402ASM-027J-YY 27 250 5 49 900 2480 0.325 400
0402ASM-030J-YY 30 250 5 49 900 2350 0.350 400
0402ASM-033J-YY 33 250 5 40 900 2350 0.400 400
0402ASM-036J-YY 36 250 5 44 900 2320 0.480 350
0402ASM-039J-YY 39 250 5 47 900 2100 0.550 340
0402ASM-040J-YY 40 250 5 44 900 2240 0.550 330
0402ASM-043J-YY 43 250 5 45 900 2030 0.650 330
Material
Ceramic
Engineer's Kits
EK-0402ASM-X
Remarks

Packing Standard
Taped / Reel
1000 [-08]
5000 [-01]
