Chip Inductors for RF Applications (Wire wound - open)

Technical Data & Specifications :

Complete Data Sheet :

Print :

Part No	Inductance L (nH)	fL (MHz)	Tol ± (%)	Q min	fQ (MHz)	SRF (GHz)	DCR max (Ω)	Rated DC Current (A)
0603AQC-3N9K-YY	3.9	100	10	50	250	10.00 min	0.025	3.50
0603AQC-5N6K-YY	5.6	100	10	42	250	6.65 min	0.045	3.00
0603AQC-6N8K-YY	6.8	100	10	42	250	6.65 min	0.045	3.00
0603AQC-7N5K-YY	7.5	100	10	42	250	3.90 min	0.045	3.00
0603AQC-9N5K-YY	9.5	100	10	42	250	3.90 min	0.050	2.70
0603AQC-010J-YY	10	100	5	45	250	3.85 min	0.050	2.70
0603AQC-011J-YY	11	100	5	45	250	3.50 min	0.050	2.50
0603AQC-012J-YY	12	100	5	45	250	3.00 min	0.055	2.50
0603AQC-015J-YY	15	100	5	45	250	3.00 min	0.070	2.50
0603AQC-016J-YY	16	100	5	45	250	2.80 min	0.070	2.50
0603AQC-018J-YY	18	100	5	42	250	2.50 min	0.080	2.40
0603AQC-022J-YY	22	100	5	42	250	2.40 min	0.085	2.30
0603AQC-024J-YY	24	100	5	42	250	2.40 min	0.085	2.25
0603AQC-027J-YY	27	100	5	42	250	2.40 min	0.095	1.60
0603AQC-030J-YY	30	100	5	42	250	2.30 min	0.100	1.60
0603AQC-033J-YY	33	100	5	42	250	2.30 min	0.110	1.60
0603AQC-036J-YY	36	100	5	40	250	2.30 min	0.140	1.60
0603AQC-039J-YY	39	100	5	40	250	2.30 min	0.160	1.50
0603AQC-043J-YY	43	100	5	40	250	2.30 min	0.180	1.00
0603AQC-047J-YY	47	100	5	40	250	2.20 min	0.190	1.00
0603AQC-051J-YY	51	100	5	40	250	2.20 min	0.210	1.00
0603AQC-056J-YY	56	100	5	40	250	2.10 min	0.230	1.00
0603AQC-068J-YY	68	100	5	40	250	2.10 min	0.380	0.90
0603AQC-072J-YY	72	100	5	40	250	2.00 min	0.410	0.85
0603AQC-082J-YY	82	100	5	40	250	2.00 min	0.485	0.80

Material

Ceramic

Standard Tolerance

Refer to table

Engineer's Kits

EK-0603AQC-X

Packing Standard
