Chip Inductors for RF Applications (Wire wound - open)

0603AS

Technical Data & Specifications :

Complete Data Sheet :

S-parameter :

STETCO Cross List :

Print :


Part No Inductance
L (nH)
fL
(MHz)
Tol
± (%)
Q
min
fQ
(MHz)
SRF
(MHz)
DCR
max
(Ω)
Rated DC
Current
(mA)
Get Sample
0603AS-1N2M-YY 1.2 250 20 30 250 >6000 min 0.030 850
Show All Parts
Material
Ceramic
Standard Tolerance
Refer to table.
Engineer's Kits
EK-0603AS-X
Remarks
i) For not listed inductance values please check availability with us.
ii) 2% and 5% tolerance available on request.
Packing Standard
Taped / Reel
4000 [-01]
1000 [-08]
15000 [-04]
