Chip Inductors For RF / Medical Applications

0603ASM New!

Technical Data & Specifications :

Complete Data Sheet :

Print :


Part No Inductance
L (nH)
fL
(MHz)
Tol
± (%)
Q
min
fQ
(MHz)
SRF
(MHz)
DCR
max
(Ω)
Rated DC
Current
(mA)
Get Sample
0603ASM-1N6K-YY 1.6 250 10 20 250 >6000 min 0.030 850
0603ASM-1N8K-YY 1.8 250 10 16 250 >6000 min 0.045 700
0603ASM-2N0K-YY 2.0 250 10 10 250 5900 min 0.17 170
0603ASM-3N3K-YY 3.3 250 10 22 250 6000 min 0.10 700
0603ASM-3N6K-YY 3.6 250 10 20 250 >6000 min 0.08 700
0603ASM-3N9K-YY 3.9 250 10 22 250 >6000 min 0.08 700
0603ASM-4N3K-YY 4.3 250 10 25 250 >6000 min 0.07 700
0603ASM-4N7K-YY 4.7 250 10 25 250 >6000 min 0.07 700
0603ASM-5N1K-YY 5.1 250 10 20 250 >6000 min 0.10 700
0603ASM-5N6K-YY 5.6 250 10 27 250 6000 min 0.12 700
0603ASM-6N8J-YY 6.8 250 5 27 250 5800 min 0.11 700
0603ASM-7N5J-YY 7.5 250 5 30 250 5400 min 0.12 700
0603ASM-8N2J-YY 8.2 250 5 30 250 5400 min 0.12 700
0603ASM-8N7J-YY 8.7 250 5 28 250 4600 min 0.109 700
0603ASM-9N5J-YY 9.5 250 5 25 250 5000 min 0.19 700
0603ASM-010J-YY 10 250 5 31 250 4800 min 0.13 700
0603ASM-011J-YY 11 250 5 35 250 4000 min 0.13 700
0603ASM-012J-YY 12 250 5 35 250 4000 min 0.13 700
0603ASM-015J-YY 15 250 5 35 250 4000 min 0.17 700
0603ASM-016J-YY 16 250 5 35 250 3200 min 0.17 700
0603ASM-018J-YY 18 250 5 35 250 3100 min 0.17 700
0603ASM-022J-YY 22 250 5 38 250 3000 min 0.19 700
0603ASM-024J-YY 24 250 5 38 250 2800 min 0.22 600
0603ASM-027J-YY 27 250 5 40 250 2800 min 0.22 600
0603ASM-030J-YY 30 250 5 40 250 2300 min 0.22 600
Material
Ceramic
Engineer's Kits
EK-0603ASM-X
Remarks

Packing Standard
Taped / Reel
1000 [-08]
4000 [-01]
15000 [-04]
