Chip Inductors For RF / Medical Applications >> 0805ASM Series

0805ASM New!

Technical Data & Specifications :

Complete Data Sheet :

Print :


Part No Inductance
L
(nH)
fL
(MHz)
Tol
± (%)
Q
min
fQ
(MHz)
SRF
(MHz)
DCR
max
(Ω)
Rated DC
Current
(mA)
Get Sample
0805ASM-2N7K-YY 2.7 250 10 80 1500 6000 min 0.08 600
0805ASM-3N3K-YY 3.3 250 10 50 1500 6000 min 0.08 600
0805ASM-5N6K-YY 5.6 250 10 53 1000 5500 min 0.11 600
0805ASM-5N8K-YY 5.8 250 10 50 1000 5500 min 0.11 600
0805ASM-6N8K-YY 6.8 250 10 50 1000 5500 min 0.11 600
0805ASM-8N0K-YY 8.0 250 10 51 1000 4700 min 0.12 600
0805ASM-8N2K-YY 8.2 250 10 50 1000 4700 min 0.12 600
0805ASM-010J-YY 10 250 5 43 1000 4300 min 0.13 600
0805ASM-012J-YY 12 250 5 50 500 4000 min 0.15 600
0805ASM-015J-YY 15 250 5 50 500 3400 min 0.17 600
0805ASM-018J-YY 18 250 5 53 500 3300 min 0.20 500
0805ASM-022J-YY 22 250 5 57 500 2600 min 0.22 500
0805ASM-027J-YY 27 250 5 55 500 2500 min 0.25 500
0805ASM-033J-YY 33 250 5 60 500 2050 min 0.27 500
0805ASM-036J-YY 36 250 5 60 500 2050 min 0.27 600
0805ASM-039J-YY 39 250 5 60 500 2000 min 0.29 500
0805ASM-047J-YY 47 200 5 65 500 1650 min 0.31 500
0805ASM-056J-YY 56 200 5 64 500 1550 min 0.34 500
0805ASM-068J-YY 68 200 5 65 500 1450 min 0.38 400
0805ASM-075J-YY 75 200 5 55 500 1300 min 0.42 400
0805ASM-082J-YY 82 150 5 67 500 1300 min 0.42 400
0805ASM-R10J-YY 100 150 5 65 500 1200 min 0.46 400
0805ASM-R12J-YY 120 150 5 52 250 1100 min 0.51 400
0805ASM-R13J-YY 130 100 5 53 250 920 min 0.56 400
0805ASM-R15J-YY 150 100 5 60 250 920 min 0.56 400
Material
Ceramic
Engineer's Kits
EK-0805ASM-X
Remarks

Packing Standard
Taped / Reel
1000 [-08]
2500 [-01]
7500 [-04]
