Chip Inductors For RF / Medical Applications >> 1206ASM Series

1206ASM New!

Technical Data & Specifications :

Complete Data Sheet :

Print :


Part No Inductance
L
(nH)
fL
(MHz)
Tol
± (%)
Q
min
fQ
(MHz)
SRF
(MHz)
DCR
max
(Ω)
Rated DC
Current
max (mA)
Get Sample
1206ASM-3N3M-YY 3.3 100 20 30 300 6000 min 0.05 1000
1206ASM-6N8K-YY 6.8 100 10 37 300 5500 min 0.07 1000
1206ASM-010J-YY 10 100 5 40 300 4000 min 0.08 1000
1206ASM-012J-YY 12 100 5 51 300 3200 min 0.08 1000
1206ASM-015J-YY 15 100 5 51 300 3200 min 0.10 1000
1206ASM-018J-YY 18 100 5 51 300 2800 min 0.10 1000
1206ASM-022J-YY 22 100 5 52 300 2200 min 0.10 1000
1206ASM-027J-YY 27 100 5 52 300 1800 min 0.11 1000
1206ASM-033J-YY 33 100 5 56 300 1800 min 0.11 1000
1206ASM-039J-YY 39 100 5 64 300 1800 min 0.12 1000
1206ASM-047J-YY 47 100 5 64 300 1500 min 0.13 1000
1206ASM-056J-YY 56 100 5 64 300 1450 min 0.14 1000
1206ASM-068J-YY 68 100 5 61 300 1200 min 0.26 900
1206ASM-082J-YY 82 100 5 66 300 1200 min 0.21 900
1206ASM-R10J-YY 100 100 5 55 300 1100 min 0.26 850
1206ASM-R12J-YY 120 100 5 75 300 1100 min 0.26 800
1206ASM-R13J-YY 130 100 5 75 300 950 min 0.31 750
1206ASM-R15J-YY 150 100 5 65 300 950 min 0.31 750
1206ASM-R18J-YY 180 50 5 75 300 900 min 0.43 700
1206ASM-R22J-YY 220 50 5 75 300 760 min 0.50 670
1206ASM-R27J-YY 270 50 5 57 300 730 min 0.56 630
1206ASM-R29J-YY 290 50 5 57 150 650 min 0.62 590
1206ASM-R33J-YY 330 50 5 55 150 650 min 0.62 590
1206ASM-R39J-YY 390 50 5 55 150 600 min 0.75 530
1206ASM-R47J-YY 470 50 5 52 150 550 min 1.30 490
Material
Ceramic
Engineer's Kits
EK-1206ASM-X
Remarks

Packing Standard
Taped / Reel
1000 [-08]
2000 [-01]
7500 [-04]
