Chip Inductors for RF Applications (Wire wound - open)

1210AS

Technical Data & Specifications :

Complete Data Sheet :

Print :


Part No Inductance
L (nH)
fL
(MHz)
Tol
± (%)
Q
min
fQ
(MHz)
SRF
(MHz)
DCR
max
(Ω)
Rated DC
Current
max (mA)
Get Sample
1210AS-010K-YY 10 50 10 50 500 4100 min 0.08 1000
1210AS-012K-YY 12 50 10 50 500 2400 min 0.09 1000
1210AS-015K-YY 15 50 10 50 500 2400 min 0.10 1000
1210AS-018K-YY 18 50 10 50 350 2400 min 0.11 1000
1210AS-022K-YY 22 50 10 55 350 2400 min 0.12 1000
1210AS-027J-YY 27 50 5 55 350 1800 min 0.13 1000
1210AS-033J-YY 33 50 5 60 350 1600 min 0.14 1000
1210AS-039J-YY 39 50 5 60 350 1500 min 0.15 1000
1210AS-047J-YY 47 50 5 65 350 1200 min 0.16 1000
1210AS-056J-YY 56 50 5 65 350 1200 min 0.16 1000
1210AS-068J-YY 68 50 5 65 350 1000 min 0.20 1000
1210AS-082J-YY 82 50 5 60 350 1000 min 0.22 1000
1210AS-R10J-YY 100 25 5 60 350 1000 min 0.24 980
1210AS-R12J-YY 120 25 5 60 350 850 min 0.26 920
1210AS-R15J-YY 150 25 5 50 100 750 min 0.29 870
1210AS-R18J-YY 180 25 5 50 100 700 min 0.31 830
1210AS-R22J-YY 220 25 5 50 100 650 min 0.35 790
1210AS-R27J-YY 270 25 5 45 100 600 min 0.42 730
1210AS-R33J-YY 330 25 5 45 100 500 min 0.49 680
1210AS-R37J-YY 370 25 5 45 100 500 min 0.52 610
1210AS-R39J-YY 390 25 5 45 100 500 min 0.54 640
1210AS-R47J-YY 470 25 5 45 100 450 min 0.60 610
1210AS-R56J-YY 560 25 5 45 100 415 min 1.00 460
1210AS-R68J-YY 680 25 5 45 100 350 min 1.15 420
1210AS-R82J-YY 820 25 5 45 100 350 min 1.93 350
Material
Ceramic
Standard Tolerance
Refer to table.
Engineer's Kits
EK-1210AS-X
Remarks
i)   For not listed inductance values please check availability with us.
ii)  2% and 5% tolerance available on request.
Packing Standard
Taped / Reel
800 [-01]
3000 [-04]
