Chip Inductors For RF / Medical Applications

1210ASM New!

Technical Data & Specifications :

Complete Data Sheet :

Print :


Part No Inductance
L (nH)
fL
(MHz)
Tol
± (%)
Q
min
fQ
(MHz)
SRF
(MHz)
DCR
max
(Ω)
Rated DC
Current
max (mA)
Get Sample
1210ASM-010K-YY 10 50 10 50 500 4100 min 0.08 1000
1210ASM-012K-YY 12 50 10 50 500 2400 min 0.09 1000
1210ASM-015K-YY 15 50 10 50 500 2400 min 0.10 1000
1210ASM-018K-YY 18 50 10 50 350 2400 min 0.11 1000
1210ASM-022K-YY 22 50 10 55 350 2400 min 0.12 1000
1210ASM-027J-YY 27 50 5 55 350 1800 min 0.13 1000
1210ASM-033J-YY 33 50 5 60 350 1600 min 0.14 1000
1210ASM-039J-YY 39 50 5 60 350 1500 min 0.15 1000
1210ASM-047J-YY 47 50 5 65 350 1200 min 0.16 1000
1210ASM-056J-YY 56 50 5 65 350 1200 min 0.16 1000
1210ASM-068J-YY 68 50 5 65 350 1000 min 0.20 1000
1210ASM-082J-YY 82 50 5 60 350 1000 min 0.22 1000
1210ASM-R10J-YY 100 25 5 60 350 1000 min 0.24 980
1210ASM-R12J-YY 120 25 5 60 350 850 min 0.26 920
1210ASM-R15J-YY 150 25 5 50 100 750 min 0.29 870
1210ASM-R18J-YY 180 25 5 50 100 700 min 0.31 830
1210ASM-R22J-YY 220 25 5 50 100 650 min 0.35 790
1210ASM-R27J-YY 270 25 5 45 100 600 min 0.42 730
1210ASM-R33J-YY 330 25 5 45 100 500 min 0.49 680
1210ASM-R39J-YY 390 25 5 45 100 500 min 0.54 640
1210ASM-R47J-YY 470 25 5 45 100 450 min 0.60 610
1210ASM-R56J-YY 560 25 5 45 100 415 min 1.00 460
1210ASM-R68J-YY 680 25 5 45 100 350 min 1.15 420
1210ASM-R82J-YY 820 25 5 45 100 350 min 1.93 350
1210ASM-1R0K-YY 1000 25 10 35 50 290 typ 2.16 330
Material
Ceramic
Engineer's Kits
EK-1210ASM-X
Remarks

Packing Standard
Taped / Reel
800 [-01]
3000 [-04]
