Transponder Coils (for RFID)

1812AFTC

Technical Data & Specifications :

Complete Data Sheet :

Print :


Part No Inductance
L (mH)
fL
(kHz)
Tol
± (%)
Q
typ
fQ
(kHz)
SRF
min
(kHz)
DCR
max
(Ω)
Sensitivity
(mV/µT)
Get Sample
1812AFTC-401K-YY 0.40 125 10 18 125 1800 12.4 7.0
1812AFTC-102K-YY 1.00 125 10 13 125 1300 48 18.0
1812AFTC-242K-YY 2.38 125 10 19 125 650 75 40.0
1812AFTC-292K-YY 2.89 125 10 19 125 620 80 40.0
1812AFTC-342K-YY 3.44 125 10 19 125 600 90 45.0
1812AFTC-412K-YY 4.15 125 10 19 125 600 120 54.0
1812AFTC-492K-YY 4.91 125 10 18 125 560 155 65.0
1812AFTC-602K-YY 6.00 125 10 18 125 530 170 81.0
1812AFTC-722K-YY 7.20 125 10 16 125 470 250 103.0
1812AFTC-742K-YY 7.36 125 10 16 125 470 250 103.0
Material
Ceramic& Ferrite
Standard Tolerance
Refer to table.
Remarks
2% and 5% tolerance available on request.
Packing Standard
Reel
600 [-01]
2200 [-04]
