Technical Data & Specifications :
Complete Data Sheet :
Print :
| Part No |
Inductance
L
(mH) |
fL
(kHz) |
Tol
± (%) |
Q
min |
fQ
(kHz) |
SRF
ref
(kHz) |
DCR
max
(Ω) |
Sensitivity
(mV/µT) |
Get Sample |
| 4408AF-371K-YY |
0.37 |
125 |
10 |
27 |
125 |
1200 |
6.4 |
9 |
|
| 4408AF-401K-YY |
0.40 |
125 |
10 |
27 |
125 |
1100 |
6.8 |
9 |
|
| 4408AF-421K-YY |
0.42 |
125 |
10 |
27 |
125 |
1100 |
8.1 |
9 |
|
| 4408AF-511K-YY |
0.51 |
125 |
10 |
27 |
125 |
1000 |
8.5 |
11 |
|
| 4408AF-701K-YY |
0.70 |
125 |
10 |
30 |
125 |
821 |
12 |
15 |
|
| 4408AF-901K-YY |
0.90 |
125 |
10 |
28 |
125 |
760 |
13.9 |
19 |
|
| 4408AF-102K-YY |
1.00 |
125 |
10 |
28 |
125 |
710 |
15 |
19 |
|
| 4408AF-112K-YY |
1.08 |
125 |
10 |
31 |
125 |
710 |
15 |
19 |
|
| 4408AF-122K-YY |
1.20 |
125 |
10 |
30 |
125 |
710 |
18 |
24 |
|
| 4408AF-132K-YY |
1.34 |
125 |
10 |
30 |
125 |
700 |
20 |
25 |
|
| 4408AF-202K-YY |
1.97 |
125 |
10 |
30 |
125 |
630 |
29.7 |
32 |
|
| 4408AF-242K-YY |
2.38 |
125 |
10 |
32 |
125 |
560 |
30.8 |
40 |
|
| 4408AF-272K-YY |
2.66 |
125 |
10 |
35 |
125 |
530 |
35.2 |
40 |
|
| 4408AF-292K-YY |
2.89 |
125 |
10 |
35 |
125 |
530 |
35.2 |
41 |
|
| 4408AF-332K-YY |
3.30 |
125 |
10 |
35 |
125 |
450 |
48 |
46 |
|
| 4408AF-342K-YY |
3.45 |
125 |
10 |
29 |
125 |
430 |
60 |
48 |
|
| 4408AF-412K-YY |
4.15 |
125 |
10 |
29 |
125 |
400 |
70 |
57 |
|
| 4408AF-472K-YY |
4.70 |
125 |
10 |
29 |
125 |
380 |
70 |
63 |
|
| 4408AF-482K-YY |
4.80 |
125 |
10 |
29 |
125 |
380 |
80 |
64 |
|
| 4408AF-492K-YY |
4.90 |
125 |
10 |
29 |
125 |
380 |
80 |
66 |
|
| 4408AF-562K-YY |
5.60 |
125 |
10 |
28 |
125 |
350 |
80 |
75 |
|
| 4408AF-682K-YY |
6.80 |
125 |
10 |
28 |
125 |
345 |
95 |
98 |
|
| 4408AF-702K-YY |
7.00 |
125 |
10 |
30 |
125 |
340 |
100 |
99 |
|
| 4408AF-712K-YY |
7.10 |
125 |
10 |
30 |
125 |
340 |
100 |
100 |
|
| 4408AF-722K-YY |
7.20 |
125 |
10 |
30 |
125 |
335 |
86.4 |
104 |
|
Material
Ceramic & Ferrite
Standard Tolerance
Refer to table.
Remarks
2% and 5% tolerance available on request.
Packing Standard
| Reel |
| 3000 [-04] |
| 1000 [-08] |
