Transponder Coils (for RFID)

4408AQ

Technical Data & Specifications :

Complete Data Sheet :

Print :


Part No Inductance
L (mH)
fL
(kHz)
Tol
± (%)
Q
min
fQ
(kHz)
SRF
ref
(kHz)
DCR
max
(Ω)
Sensitivity
(mV/µT)
Get Sample
4408AQ-701J-YY 0.70 125 5 30 125 1200 12.5 17
4408AQ-901J-YY 0.90 125 5 32 125 1100 14.5 20
4408AQ-112J-YY 1.08 125 5 34 125 950 15.7 22
4408AQ-202J-YY 1.97 125 5 34 125 700 30 35
4408AQ-242J-YY 2.38 125 5 35 125 650 31.8 42
4408AQ-272J-YY 2.66 125 5 35 125 600 35.2 45
4408AQ-292J-YY 2.89 125 5 37 125 600 35.8 48
4408AQ-332J-YY 3.30 125 5 38 125 600 43.5 55
4408AQ-472J-YY 4.70 125 5 37 125 429 68 71
4408AQ-482J-YY 4.80 125 5 37 125 433 70 74
4408AQ-492J-YY 4.90 125 5 37 125 429 71 74
4408AQ-562J-YY 5.60 125 5 37 125 404 77 86
4408AQ-682J-YY 6.80 125 5 41 125 393 85 111
4408AQ-702J-YY 7.00 125 5 41 125 393 85 118
4408AQ-712J-YY 7.10 125 5 41 125 382 88 123
4408AQ-722J-YY 7.20 125 5 40 125 381 88 119
4408AQ-812J-YY 8.10 125 5 41 125 368 94 126
4408AQ-902J-YY 9.00 125 5 41 125 354 95 133
4408AQ-952J-YY 9.50 125 5 39 125 339 114 173
4408AQ-103J-YY 10.00 125 5 39 125 330 116 214
4408AQ-133J-YY 13.50 125 5 38 125 285 138 267
Material
Ceramic & Ferrite
Standard Tolerance
Refer to table.
Remarks
2% tolerance available on request.
Packing Standard
Reel
3000 [-04]
1000 [-08]
