Suppression Coils

LSSC

Technical Data & Specifications :

Complete Data Sheet :

Print :


Part No Inductance
L (µH)
fL
(MHz)
Tol
± (%)
DCR
max
(mΩ)
Rated DC
Current
(A)
d
(mm)
Get Sample
LSSC-5R0M-00 5 1 20 5 10 1.30
LSSC-9R0M-00 9 1 20 12 6 0.95
LSSC-150M-00 15 0.1 20 24 4 0.75
LSSC-250M-00 25 0.1 20 46 3 0.63
Material
Ferrite
Standard Tolerance
±20%
Remarks

Available also without insulating material (LSSC/B)

Packing Standard
Packing Form Loose / Box
axial 200 [-00]
