Suppression Coils

MISC

Technical Data & Specifications :

Complete Data Sheet :

Print :


Part No Inductance
L (µH)
fL
(kHz)
Tol
± (%)
DCR
(mΩ)
Rated DC
Current
(A)
Get Sample
MISC-1R0M-01 1 1000 20 18 4
MISC-2R0M-01 2 1000 20 54 3
MISC-3R0M-01 3 1000 20 93 2
MISC-6R0M-01 6 1000 20 228 1.5
MISC-140M-01 14 100 20 912 0.7
MISC-300M-01 30 100 20 3240 0.4
MISC-400M-01 40 100 20 4290 0.3
MISC-101M-01 100 100 20 22800 0.15
Material
Iron Dust
Standard Tolerance
±20%
Remarks

Available also without insulating material (MISC/B)

Packing Standard
Packing Form Taped / Reel
axial 1500 [-01]
