Suppression Coils

SMSC

Technical Data & Specifications :

Complete Data Sheet :

Print :


Part No Inductance
L (µH)
fL
(kHz)
Tol
± (%)
DCR
max
(mΩ)
Rated DC
Current
(A)
Get Sample
SMSC-1R0M-01 1 1000 20 14 6
SMSC-2R0M-01 2 1000 20 24 4
SMSC-3R0M-01 3 1000 20 46 3
SMSC-6R0M-01 6 1000 20 144 2
SMSC-100M-01 10 1000 20 276 1.5
SMSC-230M-01 23 100 20 876 0.7
SMSC-500M-01 50 100 20 3600 0.4
SMSC-700M-01 70 100 20 5400 0.3
SMSC-161M-01 160 100 20 21600 0.15
Material
Iron Dust
Standard Tolerance
±20%
Remarks
Available also without insulating material (SMSC/B).
Packing Standard
Taped / Reel
1500 [-01]
