Suppression Coils

SSSC

Technical Data & Specifications :

Complete Data Sheet :

Print :


Part No Inductance
L (µH)
fL
(MHz)
Tol
± (%)
DCR
max
(mΩ)
Rated DC
Current
(A)
Ø d
(mm)
Get Sample
SSSC-4R0M-00 4 1 20 14 6 0.8
SSSC-6R0M-00 6 1 20 17 4 0.75
SSSC-8R0M-00 8 1 20 25 3 0.63, 0.65
SSSC-170M-00 17 0.1 20 63 2 0.45
Material
Ferrite
Standard Tolerance
±20%
Remarks

Available also without insulating material (SSSC/B)

Packing Standard
Packing Form Loose / Box
axial 500 [-00]
