1616FP

1616FP New!

Technical Data & Specifications :

Complete Data Sheet :

Print :


Part No Inductance
L (µH)		 Tol
± (%)		 fL
(kHz)		 SRF
typ
(MHz)		 DCR max
(mΩ)		 Rated DC Current (A) Get Sample
|sat |rms
1616FP-1R0M-01 1.0 20 100 @ 1 V 145 50 3.85 2.80
1616FP-1R5M-01 1.5 20 100 @ 1 V 105 65 2.95 2.50
1616FP-2R2M-01 2.2 20 100 @ 1 V 85 90 2.60 2.10
1616FP-3R3M-01 3.3 20 100 @ 1 V 70 110 2.15 1.60
1616FP-4R7M-01 4.7 20 100 @ 1 V 50 150 1.80 1.40
1616FP-6R8M-01 6.8 20 100 @ 1 V 43 180 1.50 1.25
1616FP-100M-01 10 20 100 @ 1 V 35 250 1.30 1.00
1616FP-150M-01 15 20 100 @ 1 V 30 390 1.00 0.85
1616FP-220M-01 22 20 100 @ 1 V 25 570 0.85 0.65
1616FP-330M-01 33 20 100 @ 1 V 18 850 0.70 0.55
1616FP-470M-01 47 20 100 @ 1 V 15 1190 0.60 0.50
1616FP-680M-01 68 20 100 @ 1 V 12 1655 0.50 0.40
1616FP-101M-01 100 20 100 @ 1 V 10 2350 0.40 0.35
Material
Ferrite
Standard Tolerance
20
Engineer's Kits
EK-1616FP-X
Packing Standard
Taped / Reel
3000 [-01]
