Chip Inductors for Power Applications (Shielded)

242408FPS

Technical Data & Specifications :

Complete Data Sheet :

S-parameter :

Print :


Part No Inductance
L (µH)		 fL
(kHz)		 Tol
± (%)		 DCR max
(mΩ)		 Rated DC Current (A) Get Sample
|sat |rms
242408FPS-R50N-01 0.5 100/1.0V 30 11.7 7.0 5.2
242408FPS-R80N-01 0.8 100/1.0V 30 15.6 6.0 4.1
242408FPS-1R5N-01 1.5 100/1.0V 30 22.1 4.0 3.6
242408FPS-2R2N-01 2.2 100/1.0V 30 31.2 3.5 2.9
242408FPS-3R3N-01 3.3 100/1.0V 30 39 2.8 2.8
242408FPS-4R7M-01 4.7 100/1.0V 20 52 2.4 2.2
242408FPS-5R6M-01 5.6 100/1.0V 20 66 2.2 2.0
242408FPS-6R8M-01 6.8 100/1.0V 20 72 2.0 1.8
242408FPS-8R2M-01 8.2 100/1.0V 20 84 1.9 1.7
242408FPS-100M-01 10 100/1.0V 20 108 1.9 1.5
242408FPS-150M-01 15 100/1.0V 20 144 1.3 1.2
242408FPS-220M-01 22 100/1.0V 20 204 1.1 1.0
242408FPS-330M-01 33 100/1.0V 20 372 0.9 0.9
242408FPS-470M-01 47 100/1.0V 20 444 0.8 0.8
Material
Ferrite
Standard Tolerance
Refer to table.
Packing Standard
Reel
2000 [-01]
