Chip Inductors for RF Applications (Wire Wound - open)

0402F

Technical Data & Specifications :

Complete Data Sheet :

Print :


Part No Inductance
L (nH)		 fL
(MHz)		 Tol
± (%)		 Impedance
Z typ (Ω)		 fZ
(MHz)		 SRF
typ
(MHz)		 DCR
max
(Ω)		 Rated DC
Current
(A)		 Get Sample
0402F-020K-YY 20 7.9 10 75 900 2580 0.040 1.600
0402F-022K-YY 22 7.9 10 85 900 2500 0.060 1.600
0402F-033K-YY 33 7.9 10 130 900 2300 0.065 1.400
0402F-036K-YY 36 7.9 10 140 900 2300 0.075 1.400
0402F-051K-YY 51 7.9 10 200 900 1930 0.075 1.300
0402F-056K-YY 56 7.9 10 230 900 1900 0.095 1.200
0402F-078K-YY 78 7.9 10 330 900 1600 0.120 1.000
0402F-R10K-YY 100 7.9 10 425 900 1400 0.150 1.000
0402F-R14K-YY 140 7.9 10 640 900 1220 0.260 0.640
0402F-R18K-YY 180 7.9 10 850 900 1090 0.280 0.600
0402F-R22K-YY 220 7.9 10 1030 900 990 0.520 0.400
0402F-R27K-YY 270 7.9 10 1400 900 880 0.550 0.380
Material
Ferrite
Engineer's Kits
EK-0402F-X
Packing Standard
Taped / Reel
5000 [-01]
1000 [-08]
