Chip Inductors for RF Applications (Wire wound - open)

0603FLP New!

Technical Data & Specifications :

Complete Data Sheet :

Print :


Part No Inductance
L (µH)		 fL
(MHz)		 Tol
± (%)		 SRF
typ
(MHz)		 DCR
max
(Ω)		 Rated DC Current (A) Get Sample
|sat |rms
0603FLP-R56M-YY 0.56 1.0 20 850 0.300 0.700 0.680
0603FLP-R68M-YY 0.68 1.0 20 670 0.350 0.620 0.600
0603FLP-1R0M-YY 1.0 1.0 20 450 0.380 0.560 0.540
0603FLP-1R5M-YY 1.5 1.0 20 175 0.520 0.440 0.420
0603FLP-2R2M-YY 2.2 1.0 20 150 0.750 0.380 0.350
0603FLP-4R7M-YY 4.7 1.0 20 55 1.050 0.300 0.300
0603FLP-6R8M-YY 6.8 1.0 20 40 1.500 0.240 0.280
0603FLP-8R0M-YY 8.0 1.0 20 40 2.500 0.200 0.200
0603FLP-100M-YY 10 1.0 20 30 2.900 0.180 0.180
0603FLP-150M-YY 15 1.0 20 25 3.600 0.140 0.140
Material
Ferrite
Engineer's Kits
EK-0603FLP-X
Packing Standard
Taped / Reel
1000 [-08]
4000 [-01]
8000 [-04]
