Common Mode Filter Chip Inductors

1210CMF

Technical Data & Specifications :

Complete Data Sheet :

Print :


Part No Impedance Z (Ω) fZ
(MHz)		 Inductance
L (µH)		 fL
(kHz)		 Tol
± (%)		 Leakage
Inductance
(µH) typ		 Capacitance
Ref.
(pF)		 DCR
max
(Ω)		 Rated DC Current
(mA)		 Get Sample
min typ
1210CMF-110X-YY 300 550 10 MHz @ 0.1 V 11 100 kHz @ 0.1 V +50/-30 0.10 12 0.40 300
1210CMF-800X-YY 1000 2600 10 MHz @ 0.1 V 80 100 kHz @ 0.1 V +50/-30 0.13 12 2.00 200
1210CMF-101X-YY 3500 5100 10 MHz @ 0.1 V 100 100 kHz @ 0.1 V +50/-30 0.13 12 2.30 150
Material
Ferrite, magnetically flat top
Packing Standard
Taped / Reel
600 [-01]
2700 [-04]
