Technical Data & Specifications :
Complete Data Sheet :
Print :
| Part No |
Inductance
L (µH) |
fL
(kHz) |
Tol
± (%) |
DCR
max
(Ω) |
Rated DC Current (A) |
Get Sample |
| | max |
|sat typ |
| 07HCP-1R0M-YY |
1.0 |
1 @ 0.25V |
20 |
0.007 |
10.0 |
7.50 |
|
| 07HCP-2R2M-YY |
2.2 |
1 @ 0.25V |
20 |
0.010 |
8.00 |
6.00 |
|
| 07HCP-3R3M-YY |
3.3 |
1 @ 0.25V |
20 |
0.013 |
6.30 |
5.00 |
|
| 07HCP-4R7M-YY |
4.7 |
1 @ 0.25V |
20 |
0.018 |
5.40 |
4.00 |
|
| 07HCP-6R8M-YY |
6.8 |
1 @ 0.25V |
20 |
0.025 |
6.50 |
3.80 |
|
| 07HCP-7R5M-YY |
7.5 |
1 @ 0.25V |
20 |
0.030 |
5.00 |
3.00 |
|
| 07HCP-100M-YY |
10 |
1 @ 0.25V |
20 |
0.040 |
5.00 |
2.60 |
|
| 07HCP-220X-YY |
22 |
1 @ 0.25V |
10,20 |
0.055 |
3.60 |
2.30 |
|
| 07HCP-330X-YY |
33 |
1 @ 0.25V |
10,20 |
0.10 |
2.50 |
1.50 |
|
| 07HCP-470X-YY |
47 |
1 @ 0.25V |
10,20 |
0.10 |
2.50 |
1.30 |
|
| 07HCP-680X-YY |
68 |
1 @ 0.25V |
10,20 |
0.14 |
2.10 |
1.10 |
|
| 07HCP-820X-YY |
82 |
1 @ 0.25V |
10,20 |
0.16 |
1.90 |
1.00 |
|
| 07HCP-101X-YY |
100 |
1 @ 0.25V |
10,20 |
0.19 |
1.60 |
0.90 |
|
| 07HCP-121X-YY |
120 |
1 @ 0.25V |
10,20 |
0.22 |
1.20 |
0.85 |
|
| 07HCP-151X-YY |
150 |
1 @ 0.25V |
10,20 |
0.36 |
1.20 |
0.85 |
|
| 07HCP-221X-YY |
220 |
1 @ 0.25V |
10,20 |
0.38 |
1.20 |
0.64 |
|
| 07HCP-271X-YY |
270 |
1 @ 0.25V |
10,20 |
0.70 |
0.95 |
0.64 |
|
| 07HCP-331X-YY |
330 |
1 @ 0.25V |
10,20 |
0.70 |
0.95 |
0.51 |
|
| 07HCP-391X-YY |
390 |
1 @ 0.25V |
10,20 |
0.89 |
0.80 |
0.50 |
|
| 07HCP-471X-YY |
470 |
1 @ 0.25V |
10,20 |
0.89 |
0.80 |
0.43 |
|
| 07HCP-681X-YY |
680 |
1 @ 0.25V |
10,20 |
1.43 |
0.70 |
0.43 |
|
| 07HCP-821X-YY |
820 |
1 @ 0.25V |
10,20 |
1.56 |
0.70 |
0.36 |
|
| 07HCP-102X-YY |
1000 |
1 @ 0.25V |
10,20 |
1.95 |
0.50 |
0.30 |
|
| 07HCP-122X-YY |
1200 |
1 @ 0.25V |
10,20 |
2.90 |
0.39 |
0.30 |
|
| 07HCP-152X-YY |
1500 |
1 @ 0.25V |
10,20 |
3.30 |
0.30 |
0.30 |
|
Standard Tolerance
L: 1µH - 10µH = ±20%, L: 22µH - 10000µH = ±10%
Remarks
Also available with shorter leads.
Packing Standard
| Loose / Box | Taped / Reel |
| 500 [-50] | 500 [-51] |
