Transponder Coils (for RFID)

1210FTC

Technical Data & Specifications :

Complete Data Sheet :

S-parameter :

Print :


Part No Inductance
L (mH)
fL
(kHz)
Tol
± (%)
Q
min
fQ
(kHz)
SRF
typ
(MHz)
DCR
max
(Ω)
Sensitivity
(mV/µT)
Get Sample
1210FTC-102K-YY 1.00 125 10.0 8 125 1.7 32.0 10
1210FTC-112K-YY 1.08 125 10.0 8 125 1.7 42.0 12
1210FTC-132K-YY 1.29 125 10.0 8 125 1.7 46.5 12
Material
Ferrite
Standard Tolerance
10%
Packing Standard
Taped / Reel
800 [-01]
3000 [-04]
