SMD Power Inductors (Magnetically Shielded)

PISA4119

Technical Data & Specifications :

Complete Data Sheet :

Print :


Part No Inductance
L (µH)		 fL
(kHz)		 Tol
± (%)		 DCR
max
(Ω)		 DCIsat DCIt
(A)		 Get Sample
PISA4119-1R0N-04 1 100/0.1V 30 0.007 10 .0 8.80
PISA4119-1R5N-04 1.5 100/0.1V 30 0.010 8.50 7.52
PISA4119-2R2M-04 2.2 100/0.1V 20 0.010 7.20 7.20
PISA4119-4R7M-04 4.7 100/0.1V 20 0.016 4.87 5.50
PISA4119-6R8M-04 6.8 100/0.1V 20 0.022 3.87 4.85
PISA4119-100M-04 10 100/0.1V 20 0.034 3.23 4.20
PISA4119-150M-04 15 100/0.1V 20 0.040 2.60 3.20
PISA4119-220M-04 22 100/0.1V 20 0.067 2.10 2.80
PISA4119-330M-04 33 100/0.1V 20 0.100 1.70 2.35
PISA4119-470M-04 47 100/0.1V 20 0.142 1.36 1.65
PISA4119-680M-04 68 100/0.1V 20 0.180 1.18 1.60
PISA4119-101M-04 100 100/0.1V 20 0.275 0.96 1.30
PISA4119-121M-04 120 100/0.1V 20 0.340 0.84 1.06
PISA4119-151M-04 150 100/0.1V 20 0.450 0.74 1.00
PISA4119-221M-04 220 100/0.1V 20 0.583 0.66 0.80
PISA4119-331M-04 330 100/0.1V 20 0.820 0.56 0.70
PISA4119-471M-04 470 100/0.1V 20 1.370 0.45 0.55
PISA4119-681M-04 680 100/0.1V 20 1.900 0.37 0.50
PISA4119-102M-04 1000 100/0.1V 20 2.800 0.33 0.40
Material
Core : Ferrite, Base : Plastic
Packing Standard
Taped / Reel
600 [-04]
