Technical Data & Specifications :
Complete Data Sheet :
Print :
Part No |
Inductance L (µH) |
fL (MHz) |
Tol ± (%) |
SRF typ (MHz) |
DCR max (Ω) |
Rated DC Current (A) |
Get Sample |
| sat |
| ΔT = 30°C |
PISG-1R0M-01 |
1.0 |
0.1 |
20 |
130 |
0.05 |
2.9 |
2.9 |
|
PISG-1R5M-01 |
1.5 |
0.1 |
20 |
115 |
0.06 |
2.6 |
2.8 |
|
PISG-2R2M-01 |
2.2 |
0.1 |
20 |
90 |
0.07 |
2.3 |
2.4 |
|
PISG-3R3M-01 |
3.3 |
0.1 |
20 |
70 |
0.08 |
2.0 |
2.0 |
|
PISG-4R7M-01 |
4.7 |
0.1 |
20 |
50 |
0.09 |
1.5 |
1.5 |
|
PISG-6R8M-01 |
6.8 |
0.1 |
20 |
45 |
0.13 |
1.2 |
1.4 |
|
PISG-100M-01 |
10 |
0.1 |
20 |
35 |
0.16 |
1.1 |
1.2 |
|
PISG-150M-01 |
15 |
0.1 |
20 |
30 |
0.23 |
0.9 |
1.1 |
|
PISG-220M-01 |
22 |
0.1 |
20 |
20 |
0.37 |
0.7 |
0.8 |
|
PISG-270M-01 |
27 |
0.1 |
20 |
15 |
0.51 |
0.65 |
0.7 |
|
PISG-330M-01 |
33 |
0.1 |
20 |
15 |
0.51 |
0.58 |
0.6 |
|
PISG-470M-01 |
47 |
0.1 |
20 |
14 |
0.64 |
0.50 |
0.5 |
|
PISG-560M-01 |
56 |
0.1 |
20 |
11 |
0.86 |
0.40 |
0.4 |
|
PISG-680M-01 |
68 |
0.1 |
20 |
11 |
0.86 |
0.40 |
0.4 |
|
PISG-101M-01 |
100 |
0.1 |
20 |
9 |
1.00 |
0.40 |
0.3 |
|
PISG-151M-01 |
150 |
0.1 |
20 |
6 |
2.00 |
0.27 |
0.25 |
|
PISG-221M-01 |
220 |
0.1 |
20 |
5.5 |
3.11 |
0.22 |
0.20 |
|
PISG-331M-01 |
330 |
0.1 |
20 |
5 |
3.80 |
0.18 |
0.16 |
|
PISG-471M-01 |
470 |
0.1 |
20 |
4 |
5.06 |
0.16 |
0.15 |
|
PISG-561M-01 |
560 |
0.1 |
20 |
3 |
9.00 |
0.15 |
0.15 |
|
PISG-681M-01 |
680 |
0.1 |
20 |
3 |
9.20 |
0.14 |
0.12 |
|
PISG-102M-01 |
1000 |
0.1 |
20 |
2 |
13.8 |
0.10 |
0.07 |
|
Material
Core : Ferrite, Base : Ceramic
Standard Tolerance
Refer to table.
