SMD Power Inductors

PISL

Technical Data & Specifications :

Complete Data Sheet :

Print :


Part No Inductance
L (µH)		 fL
(MHz)		 Tol
± (%)		 SRF
min
(MHz)		 DCR
max
(Ω)		 Rated DC Current (A) Get Sample
| sat | ΔT = 40°C
PISL-150M-04 15 0.1 20 24 0.07 2.10 1.7
PISL-220M-04 22 0.1 20 19 0.10 1.70 1.4
PISL-330M-04 33 0.1 20 15 0.16 1.40 1.2
PISL-470M-04 47 0.1 20 12 0.22 1.10 0.9
PISL-680M-04 68 0.1 20 10 0.33 0.90 0.8
PISL-101M-04 100 0.1 20 8.0 0.46 0.75 0.7
PISL-151M-04 150 0.1 20 5.5 0.69 0.60 0.55
PISL-221M-04 220 0.1 20 4.9 1.0 0.50 0.45
PISL-331M-04 330 0.1 20 3.5 1.5 0.40 0.35
PISL-471M-04 470 0.1 20 3.0 2.0 0.35 0.30
PISL-681M-04 680 0.1 20 2.3 2.8 0.25 0.25
PISL-102M-04 1000 0.1 20 1.8 3.9 0.20 0.10
PISL-222M-04 2200 0.1 20 1.8 10.0 0.12 0.10
PISL-682M-04 6800 0.1 20 1.5 30.0 0.05 0.045
Material
Core : Ferrite, Base : Plastic
Standard Tolerance
Refer to table.
Packing Standard
Taped / Reel
1000 [-04]
