Technical Data & Specifications :
Complete Data Sheet :
Print :
Part No |
Inductance L (µH) |
fL (MHz) |
Tol ± (%) |
SRF min (MHz) |
DCR max (Ω) |
Rated DC Current (A) |
Get Sample |
| sat |
| ΔT = 40°C |
PISP-6R8M-04 |
6.8 |
0.1 |
20 |
19 |
0.018 |
6.72 |
3.60 |
|
PISP-100M-04 |
10 |
0.1 |
20 |
17 |
0.026 |
5.21 |
3.60 |
|
PISP-150M-04 |
15 |
0.1 |
20 |
13 |
0.035 |
4.13 |
3.12 |
|
PISP-220M-04 |
22 |
0.1 |
20 |
10 |
0.050 |
3.54 |
2.80 |
|
PISP-330M-04 |
33 |
0.1 |
20 |
8 |
0.073 |
2.86 |
2.32 |
|
PISP-470M-04 |
47 |
0.1 |
20 |
6.1 |
0.112 |
2.34 |
1.60 |
|
PISP-680M-04 |
68 |
0.1 |
20 |
5.8 |
0.143 |
2.00 |
1.44 |
|
PISP-101M-04 |
100 |
0.1 |
20 |
4.1 |
0.230 |
1.64 |
1.28 |
|
PISP-151M-04 |
150 |
0.1 |
20 |
3.5 |
0.295 |
1.36 |
1.16 |
|
PISP-221M-04 |
220 |
0.1 |
20 |
3.1 |
0.463 |
1.12 |
0.94 |
|
PISP-331M-04 |
330 |
0.1 |
20 |
2.4 |
0.672 |
0.91 |
0.79 |
|
PISP-471M-04 |
470 |
0.1 |
20 |
2.0 |
0.996 |
0.80 |
0.64 |
|
PISP-681M-04 |
680 |
0.1 |
20 |
1.5 |
1.476 |
0.67 |
0.50 |
|
PISP-102M-04 |
1000 |
0.1 |
20 |
1.3 |
1.980 |
0.57 |
0.42 |
|
PISP-222M-04 |
2200 |
0.1 |
20 |
1.0 |
4.488 |
0.34 |
0.30 |
|
PISP-103M-04 |
10000 |
0.1 |
20 |
0.44 |
21.480 |
0.17 |
0.12 |
|
Material
Core : Ferrite, Base : Plastic
Standard Tolerance
Refer to table.
