Suppression Coils

Technical Data & Specifications :

Complete Data Sheet :

Print :

Part No	Inductance L (µH)	fL (MHz)	Tol ± (%)	DCR max (mΩ)	Rated DC Current (A)	d (mm)
MSSC-3R0M-00	3	1	20	6	9	1.18
MSSC-6R0M-00	6	1	20	10	6	0.95
MSSC-110M-00	11	0.1	20	20	4	0.70
MSSC-130M-00	13	0.1	20	24	3	0.70
MSSC-200M-00	20	0.1	20	54	3	0.50

Material

Ferrite

Standard Tolerance

±20%

Remarks

Available also without insulating material (MSSC/B)

Packing Standard

Packing Form	Loose / Box
Axial	350 [-00]
